Die for Crimp Tool, TL-336T1
Die for Crimp Tool
Part Number: TL-336T1
Die sizes 0.028″ (0.7112mm), 0.039″(0.9906mm), 0.047″ (1.1938mm), 0.100″ (2.54mm), 0.128″ (3.2512mm), 0.151″ (3.8354mm).
Dielectric Insertion Tool, SMA Jack, JyeBao, ST-003
Dielectric Insertion Tool, SMA Jack, JyeBao,
Part Number: ST-003,
Dielectric Insertion Tool,
for SMA Plug (Conventional Male),
50 ohm,
Dielectric Insertion Tool, SMA Jack, JyeBao, ST-004
Dielectric Insertion Tool, SMA Jack, JyeBao,
Part Number: ST-004,
Dielectric Insertion Tool,
for SMA Jack (Conventional Female),
50 ohm,
Directional Coupler, 800-2700 MHz, 10dB, RFS-0827-10
Directional Coupler, N Jack, 10dB, 800MHz to 2700MHz
Part Number: RFS-0827-10
RFShopUK– Other Directional Couplers
RFDenda.com– Directional Couplers
Directional Coupler Specifications and Plots
Technical Specifications: 800-2700Mhz Directional Coupler but work well down to 600MHz)
Model: RFS-0827-10
Coupling(dB): 10 ±1
Frequency(MHz): 800-2700 (600 -2700)
Insertion Loss(Db): 0.7dB (This includes 0.5dB loss due to coupling)
Isolation(dB): ≥20
VSWR: ≤1.25:1
Power Rating(w): 200
Impedance (ohm): 50
Temperature(deg C): -35 ~ +125
Connector: N (fem)
Colour: Grey
Size: 156*63*16.5
Directional Coupler, N Jack, 20dB, 700MHz to 2700MHz, RFS-0727-20
Directional Coupler, N Jack, 20dB, 700MHz to 2700MHz
Part Number: RFS-0727-20
RFShopUK– Other Directional Couplers
RFDenda.com– Directional Couplers
Directional Coupler Specifications and Plots
Technical Specifications: (800-2700Mhz Directional Coupler but work well down to 600 MHz)
Model: RFS-0827-20
Coupling(dB): 20 ±1.1
Frequency(MHz): 800-2700 (600 -2700)
Insertion Loss(Db): 0.2dB (This includes 0.1dB loss due to coupling)
Isolation(dB): ≥20
VSWR: ≤1.25:1
Power Rating(w): 200
Impedance (ohm): 50
Temperature(deg C): -35 ~ +125
Connector: N (fem)
Colour: Grey
Size: 156*63*16.5
Directional Coupler, N Jack, High Power 3dB, 800-2500 MHz, YFTX-3HC-0825
Directional Coupler, N Jack, High Power 3dB, 800-2500 MHz
Part Number: YFTX-3HC-0825
F Connector, male, crimp, fits RG316 F3100-0316
Part Number: F3100-0316 , CLICK FOR DATA SHEET
F Plug (Male) Connector, Crimp, fits RG179, CH-FMEP-179
Part Number: CH-FMEP-179
Feed Through Termination, BNC Plug to Jack, 1GHZ, 2W, 50ohm, F-BMBF0/1G2W50
Feed Through Termination, BNC Plug to Jack, (Conventional Male to Female), 1GHZ, 2W, 50ohm, F-BMBF0/1G2W50
Part Number: F-BMBF0/1G2W50
Feed through terminations are used to match 50ohm or 75 ohm lines to the higher impedance inputs of, oscilloscopes and other electronic instruments.
The can be used either way around. They are essentially just 50ohm or 75 ohm resistors to ground but connected to both ports.
Feed Through Terminations, BNC, 75ohm, 1Mohm F-BMBF0/1G2W75
Feed through terminations are used to match 50ohm or 75 ohm lines to the higher impedance inputs of, oscilloscopes and other electronic instruments.
The can be used either way around. They are essentially just 50ohm or 75 ohm resistors to ground but connected to both ports.
Part Number: F-BMBF0/1G2W75
Feed Through Termination, BNC Plug to BNC Jack, (Conventional Male to Female), 1GHz, 2W, 75ohm, F-BMBF0/1G2W75
