CRC9 Plug Connector, (Conventional Male), fits RG316, CH-CRC9P-0316
CRC9 Plug Connector, (Conventional Male), fits RG316, CH-CRC9-0316
Part Number: CH-CRC9-0316 ,
Crimp Die, Insert-C for Ergonomic Crimp Tool-CRT-2
Crimp Die, Insert-C for Ergonomic Crimp Tool-CRT-2
Part Number: Insert-C
Interchangeable crimp insert to be used with crimping tool CRT-1 & CRT-2
Crimp Sizes: 10.7mm, 3.3mm, 2.55mm, 2.4mm, 1.6mm.
Crimping Die – 0.255″ (6.5mm), 0.187″ (4.75mm), 0.068″ (1.72mm), 0.213″ (5.4mm) HT-3A4A
Part Number: HT-3A4 , Die sizes 0.255″ (6.5mm), 0.068″ (1.72mm) , 0.213″ (5.41mm), 0.187″ (4.75mm)
Crimping Tool with Die for LMR600, TL-136BR
Crimping Tool with Die for LMR600,
Part Number: TL-136BR,
Crimp Tool with Ratchet,
Fitted Die for LMR600 included. (15.5mm/0.610″ and 4.72mm/0.186″),
DC Block, BNC Plug to BNC Jack, 3GHz, 100V-DC, 50ohm, DC-BMBF03G100V50
Part Number: DC-BMBF0/3G100V50
DC Block, BNC Plug to BNC Jack, (Conventional Male to Female), 3GHz, 100V-DC, 50ohm, DC-BMBF03G100V50
DC block, N Plug to N Jack, (Conventional Male to Female), 5GHz, 25V-DC, 50ohm, DC-NMNF0/5G25V50
Part Number: DC-NMNF0/5G25V50
DC block, N Plug to N Jack, (Conventional Male to Female), 5GHz, 25V-DC, 50ohm, DC-NMNF0/5G25V50
DC Block, SMA Plug to SMA Jack, (Conventional Male to Female), 5GHz, 100V -DC, 50ohm, C-AMAF0/5G100V50
Part Number: DC-AMAF0/5G100V50
DC BLOCK, SMA Plug to SMA Jack, (Conventional Male to Female), 5GHz, 100V -DC, 50ohm, C-AMAF0/5G100V50
DC Converter-Wide Range Power Conditioner, 100W, DC-Converter-WRPC-100W
Product Number: DC-Converter-WRPC-100W
DC Converter-Wide Range Power Conditioner, 100W, DC-Converter-WRPC-100W
DC-NMNF0/5G100V50, DC BLOCK
Part Number: DC-NMNF0/5G100V50
DC Block, N Plug to N Jack, (Conventional Male to Female), 5GHz, 100V-DC, 50ohm, DC-NMNF0/5G100V50
Die for Crimp Tool, TL-336T1
Die for Crimp Tool
Part Number: TL-336T1
Die sizes 0.028″ (0.7112mm), 0.039″(0.9906mm), 0.047″ (1.1938mm), 0.100″ (2.54mm), 0.128″ (3.2512mm), 0.151″ (3.8354mm).
Directional Coupler, 800-2700 MHz, 10dB, RFS-0827-10
Directional Coupler, N Jack, 10dB, 800MHz to 2700MHz
Part Number: RFS-0827-10
RFShopUK– Other Directional Couplers
RFDenda.com– Directional Couplers
Directional Coupler Specifications and Plots
Technical Specifications: 800-2700Mhz Directional Coupler but work well down to 600MHz)
Model: RFS-0827-10
Coupling(dB): 10 ±1
Frequency(MHz): 800-2700 (600 -2700)
Insertion Loss(Db): 0.7dB (This includes 0.5dB loss due to coupling)
Isolation(dB): ≥20
VSWR: ≤1.25:1
Power Rating(w): 200
Impedance (ohm): 50
Temperature(deg C): -35 ~ +125
Connector: N (fem)
Colour: Grey
Size: 156*63*16.5
Directional Coupler, N Jack, 20dB, 700MHz to 2700MHz, RFS-0727-20
Directional Coupler, N Jack, 20dB, 700MHz to 2700MHz
Part Number: RFS-0727-20
RFShopUK– Other Directional Couplers
RFDenda.com– Directional Couplers
Directional Coupler Specifications and Plots
Technical Specifications: (800-2700Mhz Directional Coupler but work well down to 600 MHz)
Model: RFS-0827-20
Coupling(dB): 20 ±1.1
Frequency(MHz): 800-2700 (600 -2700)
Insertion Loss(Db): 0.2dB (This includes 0.1dB loss due to coupling)
Isolation(dB): ≥20
VSWR: ≤1.25:1
Power Rating(w): 200
Impedance (ohm): 50
Temperature(deg C): -35 ~ +125
Connector: N (fem)
Colour: Grey
Size: 156*63*16.5
