Cable Assembly, SMA Jack Bulkhead, to UFL Plug RA, RG178, 100mm, A85UFL-178-100
Cable Assembly, SMA Jack Bulkhead, to UFL Plug RA, RG178, 100mm
Part Number: A85UFL-178-100
A85- SMA Jack (Conventional Female), Bulkhead
UFL- Plug (conventional Male), Right Angle
Cable Type: RG178
Length: 100mm
Cable Assembly, SMA Jack Bulkhead, to UFL Plug RA, RG178, 50mm, A85UFL-178-50
Cable Assembly, SMA Jack Bulkhead, to UFL Plug RA, RG178, 50mm
Part Number: A85UFL-178-50
A85- SMA Jack (Conventional Female), Bulkhead
UFL- Plug (conventional Male), Right Angle
Cable Type: RG178
Length: 50mm
Cable Assembly, SMA Jack to Fakra Jack, SMA Jack, 200 Series, 150mm, A80Fakra80-200-150
Cable Assembly, SMA Jack to Fakra Jack, 200 Series, 150mm,
Part Number: A80Fakra80-200-150
Coaxial Cable Assembly,
1: SMA
Jack (Conventional Female/ Socket),
2: Fakra (Universal-Sea Blue) Water Blue,
Jack (SMB Jack Standard),
200 Series Cable,
150mm Length,
Bespoke Cable Assemblies available. Contact us directly for a free quote.
Cable Assembly, SMA Jack to Fakra Plug , 200 Series, 150mm, A80Fakra30-200-150
Cable Assembly, SMA Jack to Fakra Plug, 200 Series, 150mm,
Part Number: A80Fakra30-200-150
Coaxial Cable Assembly,
1: SMA
Jack (Conventional Female/ Socket),
2: Fakra (Universal-Sea Blue) Water Blue,
Plug (SMB Plug Standard),
200 Series Cable,
150mm Length,
Bespoke Cable Assemblies available. Contact us directly for a free quote.
Cable Assembly, SMA Jack to Fakra Plug , RG58, 150mm, A80Fakra30-58-150
Cable Assembly, SMA Jack to Fakra Plug , RG58, 150mm,
Part Number: A80Fakra30-58-150
Coaxial Cable Assembly,
1: SMA
Jack (Conventional Female/ Socket),
2: Fakra (Universal-Sea Blue) Water Blue,
Plug (SMB Plug Standard),
RG58 Cable,
150mm Length,
Bespoke Cable Assemblies available. Contact us directly for a free quote.
Cable Assembly, SMA Jack to Fakra Plug , RG58, 300mm, A80Fakra30-58-300
Cable Assembly, SMA Jack to Fakra Plug , RG58, 300mm,
Part Number: A80Fakra30-58-300
Coaxial Cable Assembly,
1: SMA
Jack (Conventional Female/ Socket),
2: Fakra (Universal-Sea Blue) Water Blue,
Plug (SMB Plug Standard),
RG58 Cable,
300mm Length,
Bespoke Cable Assemblies available. Contact us directly for a free quote.
Cable Assembly, SMA Plug RP to SMA Jack RP, 1.13mm cable, 0.45M, A60A95-1.13-450
Cable Assembly, SMA Plug RP to SMA Jack RP, 1.13mm cable, 0.45M,
Part Number: A60A95-1.13-450,
Connector 1: SMA
Reverse Polarity Plug (Female Inner Pin),
Connector 2:SMA
Reverse Polarity Jack (Male Inner Pin),
Cable Type: 1.13mm * (Covered in Protective layer of 18mm Heat Shrink Tubing)
Length: 0.45m,
*The 1.13 Cable in this assembly is designed to fit through small spaces such a window frame, to enable a signal through a closed window. The Construction is a flat ‘tape like’ cable.
Cable Data
Construction:
Inner Conductor Silver Plated Copper 7/0.08
Dielectric FEP 0.68
Shield Silver Plated Copper 0.9
Jacket FEP (Grey) 1.13
Electrical Characteristics:
Impedance : 50Ω ±3Ω
Capacitance : 98pF/m
Velocity of Propagation : 69%
Max. Operating Frequency : 6GHz
Dielectric Strength : 500V AC / Minute
Rating Current : 1.5A
Minimum Bend Radius : 4.5mm
Spark Test : 2500VRMS
Operating Temp. Range : -55°C to +155°C
Cable Assembly, SMA Plug RP to SMA Jack RP, 1.13mm cable, 0.3M, A60A95-1.13-300
Cable Assembly, SMA Plug RP to SMA Jack RP, 1.13mm cable, 0.3M,
Part Number: A60A95-1.13-300,
Connector 1: SMA
Reverse Polarity Plug (Female Inner Pin),
Connector 2:SMA
Reverse Polarity Jack (Male Inner Pin),
Cable Type: 1.13mm * (Covered in Protective layer of 18mm Heat Shrink Tubing)
Length: 0.3m,
*The 1.13 Cable in this assembly is designed to fit through small spaces such a window frame, to enable a signal through a closed window. The Construction is a flat ‘tape like’ cable.
Cable Data
Construction:
Inner Conductor Silver Plated Copper 7/0.08
Dielectric FEP 0.68
Shield Silver Plated Copper 0.9
Jacket FEP (Grey) 1.13
Electrical Characteristics:
Impedance : 50Ω ±3Ω
Capacitance : 98pF/m
Velocity of Propagation : 69%
Max. Operating Frequency : 6GHz
Dielectric Strength : 500V AC / Minute
Rating Current : 1.5A
Minimum Bend Radius : 4.5mm
Spark Test : 2500VRMS
Operating Temp. Range : -55°C to +155°C
Cable Assembly, SMA Plug to MMCX Plug RA, RG174, 0.3M, A30MMCX39-174-300
Cable Assembly, SMA Plug to MMCX Plug RA, RG174, 0.3M
Part Number: A30MMCX39-174-300
Connector 1: SMA Plug (Male pin)
Connector 2: MMCX Plug (Male pin) Right Angled
Cable Type: RG174
Length: 300mm
Cable Assembly, SMA Plug to N Plug, 200 series, 1M, A30N30-200-1000
Cable Assembly, SMA Plug to N Plug, 200 series, 2M, A30N30-200-1000
Part Number: A30N30-200-1000
Connector 1: SMA Plug (Conventional Male)
Connector 2: N Plug (Conventional Male)
Cable Type: low loss 200 series 0.6 dB per metre at 2.5GHz (diameter ~5mm)
Length: 1000mm
RFShopUK- Other A30N30 Assemblies
All Assemblies can be made to specific requirements, for a quote please contact us directly.
Cable Assembly, SMA Plug to N Plug, 200 series, 2M, A30N30-200-2000
Cable Assembly, SMA Plug to N Plug, 200 series, 2M, A30N30-200-2000
Part Number: A30N30-200-2000
Connector 1: SMA Plug (Conventional Male)
Connector 2: N Plug (Conventional Male)
Cable Type: low loss 200 series 0.6 dB per metre at 2.5GHz (diameter ~5mm)
Length: 2000mm
RFShopUK- Other A30N30 Assemblies
All Assemblies can be made to specific requirements, for a quote please contact us directly.
Cable Assembly, SMA Plug to SMA Jack BH, 195 cable, 2M,
Cable Assembly, SMA Plug to SMA Jack BH, 195 cable, 2M,
Part Number: A30A85-195-2000,
Connector 1: SMA Plug (Conventional Male),
Connector 2: SMA Jack (Conventional Female),
: Bulkhead,
Cable Type: 195 series,
Length: 2m,
