lightningprotector n e1765707367202 CH-LP-N30N85-6 - RFShop UK <p><strong>Lightning Protector (Surge Arrester)</strong> with N Type <strong>Plug (Male)</strong> to <strong>Jack (Female) Bulkhead</strong> connection, rated <strong>DC–6 GHz</strong>—ideal for inline protection of RF coax feeds and antenna runs (requires correct grounding/bonding).</p>

ch lp n30 n85 6 CH-LP-N30N85-6 - RFShop UK <p><strong>Lightning Protector (Surge Arrester)</strong> with N Type <strong>Plug (Male)</strong> to <strong>Jack (Female) Bulkhead</strong> connection, rated <strong>DC–6 GHz</strong>—ideal for inline protection of RF coax feeds and antenna runs (requires correct grounding/bonding).</p>

CH LP N30N85 6b CH-LP-N30N85-6 - RFShop UK <p><strong>Lightning Protector (Surge Arrester)</strong> with N Type <strong>Plug (Male)</strong> to <strong>Jack (Female) Bulkhead</strong> connection, rated <strong>DC–6 GHz</strong>—ideal for inline protection of RF coax feeds and antenna runs (requires correct grounding/bonding).</p>

Quantity	Discount (%)	Price
1 - 5	—	£16.11
6 - 49	10 %	£14.50
50 - 99	15 %	£13.69
100+	20 %	£12.89

Lightning Protector, N Plug to N Jack, Bulkhead, 6 GHz, CH-LP-N30N85-6

Name: Lightning Protector, N Plug to N Jack, Bulkhead, 6 GHz, CH-LP-N30N85-6 - RFShop UK
Brand: Chang Hong
SKU: CH-LP-N30N85-6
Price: 16.11 GBP
Availability: InStock

Lightning Protector (Surge Arrester) with N Type Plug (Male) to Jack (Female) Bulkhead connection, rated DC–6 GHz—ideal for inline protection of RF coax feeds and antenna runs (requires correct grounding/bonding).

Original price was: £21.47.Current price is: £16.11. Ex Vat

40 in stock

Description

Product Description

Lightning Protector (Surge Arrester) – N Plug to N Jack Bulkhead, DC–6 GHz

Part Number: CH-LP-N30N85-6

Protect RF equipment connected to outdoor antennas and long coax runs by diverting surge energy away from sensitive inputs.
This device is designed to be installed inline on an RF coax feed and must be correctly bonded/grounded as part of a complete lightning/surge protection setup.

Key Features

Frequency range: DC–6 GHz
Connectors: N Plug (Male, conventional) to N Jack (Female, conventional)
Bulkhead/panel-mount style (ideal for enclosure or entry-panel mounting)
Measured RF performance plots available (S11/S21)

Performance (from plot)

Typical insertion loss (S21): ~0.14 dB @ 61 MHz, ~0.34 dB @ 1.79 GHz, ~0.70 dB @ 3.43 GHz
Typical return loss (S11): ~26.6 dB @ 61 MHz, ~22.7 dB @ 1.79 GHz, ~21.0 dB @ 3.43 GHz

Note: Values above are taken directly from the supplied test plot for the 6 GHz model. See PDF for full trace/markers.

Specifications

Product type	Lightning Protector / Surge Arrester (coaxial)
Connector A	N Plug (Male, conventional)
Connector B	N Jack (Female, conventional) – Bulkhead
Frequency	DC–6 GHz
Mounting	Bulkhead / panel mount

Installation Notes

Install at the building/enclosure entry point wherever possible.
For effective protection, ensure the bulkhead body/ground lug is bonded to a proper earth/ground system.
Lightning/surge protection is a system: correct earthing and cable routing are essential.
