Directional Coupler, 800-2700 MHz, 10dB, RFS-0827-10

Product Description

Directional Coupler, N Jack, 10dB, 800MHz to 2700MHz

Part Number: RFS-0827-10

RFShopUK– Other Directional Couplers

RFDenda.com– Directional Couplers

Datasheet

Directional Coupler Specifications and Plots

Technical Specifications:                    800-2700Mhz Directional Coupler but work well down to 600MHz)

Model:                                                  RFS-0827-10

Coupling(dB):                                      10 ±1

Frequency(MHz):                                800-2700      (600 -2700)

Insertion Loss(Db):                             0.7dB  (This includes 0.5dB loss due to coupling)

Isolation(dB):                                       ≥20

VSWR:                                                ≤1.25:1

Power Rating(w):                                200

Impedance (ohm):                              50

Temperature(deg C):                          -35 ~ +125

Connector:                                          N (fem)

Colour:                                                Grey

Size:                                                    156*63*16.5
