2.4–2.5 GHz Yagi Antenna — 16 dBi, N-Female (YA-24-01)

Product Description

Overview

Directional Yagi for 2.4 GHz ISM/Wi-Fi links. Delivers 16 dBi gain with a tight ≈37° × 37° beam, vertical polarisation, and a compact, robust build for outdoor CPE, point-to-point bridges and telemetry. Feed and reflector geometry are built to design spec to maintain the modelled impedance and beam shape.

Key features

• Frequency: 2400–2500 MHz
• Gain: 16 dBi (directional)
• Polarisation: Vertical
• 3 dB Beamwidth: ≈37° (H) × 37° (V)
• VSWR: < 1.5:1
• Connector: N-Female, with 45 cm RG58 pigtail
• Durable, lightweight, good wind resistance (rated to 120 km/h)
• Supplied with U-bolt mounting hardware

Typical applications

• 2.4 GHz point-to-point and point-to-multipoint links
• Client premises equipment (CPE) and long-reach Wi-Fi bridges
• Industrial telemetry / wireless sensing in the 2.4 GHz ISM band

Specifications

• Model: YA-24-01
• Frequency range: 2400–2500 MHz
• Gain: 16 dBi
• Type: Yagi (directional)
• Polarisation: Vertical
• Beamwidth (3 dB): ~37° (H) / ~37° (V)
• VSWR: < 1.5:1
• Connector: N-Female (with 45 cm RG58)
• Operating temperature: −30 °C to +60 °C
• Dimensions (L×W×H): 693 × 125 × 74 mm
• Weight: 820 g
• Wind load rating: 120 km/h
• Mounting: U-bolts (mast mount)

Datasheet available at https://rfshop.co.uk/wp-content/uploads/2020/06/1575447478001-1.pdf
